Replacement 10″ Solid Friction Disc (6.5″ ID)
Category: Friction Discs SKU: TD10CL6952FD$119.00
In stock (can be backordered)
For Use in 10″ Twin Disc, Rockford, NACD and WPT Power Power Takeoffs
10″ solid friction disc (measurement from tooth groove to opposite groove) with less common 6.5″ interior diameter
Also replaces part numbers:Â CL6952, 2-03560, WTD-10-064
Includes QTY 1 Solid Friction Disc
See Product Description to confirm dimensions for proper fit.
Need help? We’re available:
We're available Mon–Thurs 8:30–5, Fri 8:30–3 (EST)
1-800-233-6539Chat with an expertDescription
This 10″ friction disc, replaces the fiber discs for Twin Disc, Rockford, NACD and WPT Power ten-inch PTO clutches that have the same dimensions. Note that while the more common 10″ friction disc interior diameter is 5.5″, this friction disc has and ID of 6.5″ which was used in a smaller number of clutch packs mostly made by Rockford and NACD. While these are usually referred to as 10″ discs, the disc actually measures closer 10.75″ from tip-of-tooth to the opposite tip- of-tooth or 10″ from tooth groove to opposite tooth groove and has a thickness of just under 0.5″.
Also replaces NACD part number 203561AM, Rockford part number 2-03561, Twin Disc part number CL6952, and WPT Power part number WTD-10-064.
Includes QTY 1 Solid Friction Disc
Specs
| Weight | 4 lbs |
|---|---|
| Dimensions | 12 × 12 × 1 in |
| Brand Fit | NACD, Rockford, Twin Disc, WPT Power |
| Common Size Reference | "Ten-Inch" Solid Friction Disc (see description for detailed measurements) |
| Product Type | Clutch Disc |
